Name: Aruba S4B22A#ABA Ethernet Switch
Brand: Aruba
SKU: S4B22A#ABA
Availability: InStock

Key Features

Effectively reduces downtime with improved network performance
Can work as layer 3 routing for scalable network design
Rack mounting enables you to organize wires & secure cables for professional installation
Managed switch provides a reliable foundation for your network
Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
Comes in black color for better adaption to the space

Switch

CX 8325

Product Information

Features

Dimensions

Product Name:

CX 8325H 16p QSFP28 40G/100G Front-to-Back 4xFan 2xPSU Switch

Product Series:

CX 8325

Product Line:

Port Details:

2x 10 Gigabit Ethernet SFP+ Expansion Slot
1x USB Type-C Console Port
1x USB Type A AUX
1x RJ-45 Management Port
1x RJ-45 Console Port
16x 100 Gigabit Ethernet QSFP28 Expansion Slot

Rack Units:

Fanless:

Routing:

Yes

Stacking:

Redundant PSU:

Yes

PoE Budget (W):

Power Consumption (W):

500

Height:

1.71 in

Width:

17.26 in

Depth:

21.1 in

Description

The HPE Aruba Networking CX 8325 Switch Series serves as both a campus (core and aggregation) and data center (ToR and EoR) switch. This game-changing solution offers an innovative approach to dealing with network demands in the mobile, cloud, and IoT era. CX 8325 Switch Series is based on AOS-CX, with its microservices style modular architecture, REST APIs, Python scripting capabilities and NAE is a modern software system that automates and simplifies critical and complex network tasks, delivers enhanced fault tolerance and facilitates zero-service disruption during planned or unplanned control-plane events. CX 8325 provides line rate 1GbE, 10GbE, 25GbE, and 40GbE in a compact 1U form factor.

CX 8325P, delivers key solutions for providers in their 5G (Radio Access Network) and edge computing deployments. CX 8325H are highperformance 1/10/25/40/100G half-width switches ideal for smaller, edge or colocation data centers, and wide variety of compute and storage networking use cases.|

What's new

High-performance with 2,000 Mpps. HPE Aruba Networking designed the data center for core/aggregation in the campus or top-of-rack (ToR) or End of Row (EoR).
AOS-CX delivers automation and programmability using built-in REST APIs and Python scripts. High availability with industry-leading VSX redundancy, and redundant power supplies and fans.
Intelligent monitoring, visibility, and remediation with HPE Aruba Networking Network Analytics Engine and dynamic VXLAN for deep segmentation in data center and campus networks with BGPEVPN.
Compact 1U switches with 1GbE, 10GbE, 25GbE, 40GbE, and 100GbE connectivity. Advanced layer 2/3 feature set includes BGP, OSPF, VRF, VXLAN, and IPv6.
CX 8325P-32C switch supports PTP (1588v2), Class C (G.8275.1/G.8275.2), Synchronous Ethernet (SyncE, G.8262.1), Global Navigation Satellite System (GNSS) to support Telco Boundary Clock.

CX 8325H has two variations:

2.16Tbps half-width fixed switch that supports 18 ports of 1/10/25 and 4 ports of 40/100GbE
4Tbps half-width fixed switch that supports 16 ports of 40/100 GbE |

Features

Game-changing Business Agility

The HPE Aruba Networking CX 8325 Switch Series is a campus core and aggregation switch and data center (ToR) solution with an innovative and powerful approach to dealing with the cross-domain demands of the mobile, cloud, and IoT era.
