HPE
JL807A#ABA
RFQ Only
HPE Networking Instant On Switch 1960 is a smart-managed, fixed-configuration Gigabit stackable switch designed for small and growing businesses. It offers flexible management through a local web GUI, Instant On mobile app, and cloud-based web portal, plus support for stacking and 10G connectivity.
SKU: JL807A#ABA
Features
Key Features
- High-level Gigabit with 10 GbE Networking for Advanced Small Businesses
- Each model of the HPE Networking Instant On Switch 1960 series includes four 10 GbE connections to connectto servers, network storage devices, or to other switches.
- Two connections of 10 GBASE-T deliver 10 GbE over copper Category 5/6a cabling for simple, affordable, high-bandwidth connections to a maximum distance of 100 meters.
- With PoE models, up to 30W PoE power delivery is available for Class 4 PoE devices like access points,surveillance cameras and VoIP phones, and up to 60W PoE power delivery is available for Class 6 PoE deviceslike pan-tilt zoom cameras and video-enabled IP-phones.
- Simplify Network Deployment and Management for Small Organizations
- The HPE Networking Instant On Switch 1960 series is a complete portfolio for increased small business flexibility.It consists of six models including two 24-port and two 48-port models in PoE and non-PoE configurations, a 12-port multi-rate switch, and a 12-port 10-Gigabit aggregation switch.
- The 12-port, 24-port, and 48-port PoE models come with a power budget of 480W, 370W and 600Wrespectively to support the latest PoE-powered IoT devices.
- The HPE Networking Instant On Switch 1960 series can be deployed using two management modes - InstantOn cloud-management (access via mobile app and/or web portal) and the local web GUI.
- Each switch has a pull-out tag, known as a luggage tag, on the front panel of the switch.
- The tag includes a QR code that includes switch ID information (SKU number, SKU name, serial number, andMAC address) for easy switch onboarding through Instant On mobile app.
Switch
1960
Product Information
Features
Dimensions
Product Name:
Networking Instant On Switch 20p Gigabit CL4 4p Gigabit CL6 PoE 2p 10GBT 2p SFP+ 370W 1960
Product Series:
1960
Product Line:
Instant On
Port Details:
2x 10 Gigabit Ethernet SFP+ Uplink Port
24x 1 GBASE-T Gigabit Ethernet PoE RJ-45 Network Port
2x 10 GBASE-T Gigabit Ethernet RJ-45 Network Uplink Port
24x 1 GBASE-T Gigabit Ethernet PoE RJ-45 Network Port
2x 10 GBASE-T Gigabit Ethernet RJ-45 Network Uplink Port
Rack Units:
-
Fanless:
No
Routing:
No
Stacking:
Yes
Redundant PSU:
No
PoE Budget (W):
370
Power Consumption (W):
80
Height:
1.73 in
Width:
17.42 in
Depth:
13.8 in
Weight:
10.36 lb
Description
Overview
HPE Networking Instant On Switch 1960 series consist of advanced, smart-managed, fixed configuration Gigabit stackable switches designed for small and growing businesses that are easy to deploy and affordable. These switches are designed to scale as business grows, making adding more employees, devices and applications simple.
The Instant On 1960 switches are made to handle today's bandwidth-heavy applications like voice and video conferencing, enabling consistent connectivity to improve user experience and application performance. These switches come with flexible management options: local web GUI or Instant On mobile app and cloud-based web portal.
What's new
- Simplify network management by stacking up to four Instant On 1960 switches and managing them through one single IP address. Stacking supported via local and cloud-managed stacking modes.
- Smart-managed layer 2+ Ethernet access switch series ready to deploy in 12-port, 24-port, and 48-port for non-PoE and PoE models that support Class 4 and Class 6 PoE.
- The Networking Instant On 1960 aggregation switches comes with twelve 10 GBase-T and four SFP+ ports, providing 10 G connectivity to servers, network storage devices and access switches alike.
- For environments with heavy bandwidth needs, 10 GBase-T and SFP+ uplink ports deliver lightning-fast network speeds and nearly eliminates traffic bottlenecks.
- HPE Networking Instant On mobile app and/or cloud-based web portal for easy network management onsite or remotely.
