Name: HPE S3K89A Ethernet Switch
Brand: HPE
SKU: S3K89A
Availability: InStock

Key Features

Effectively reduces downtime with improved network performance
With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
Rack mounting enables you to organize wires & secure cables for professional installation
Managed switch provides a reliable foundation for your network
Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components

Switch

5945

Product Information

Features

Dimensions

Product Name:

Comware 5945 Ethernet Switch

Product Series:

5945

Product Line:

Comware

Port Details:

2x Gigabit Ethernet SFP Expansion Slot
4x Expansion Module Slot
1x Console Port
1x USB Port
1x SFP Management Port
1x Mini USB Port

Rack Units:

Fanless:

Routing:

Stacking:

Redundant PSU:

PoE Budget (W):

Power Consumption (W):

650

Description

High-density 100GbE/40GbE/25GbE/10GbE spine/top-of-rack (ToR) connectivity and Cut-through switching with low-latency and wire speed performance.
New 32G/16G support for storage networking and ROCE V1/V2 for RDMA High-Performance computing.VXLAN, EVPN, and MPLS support for virtualized environments.
Greater flexibility with two/four slot options for varying use cases such as MACsec 256-bit encryption, high-performance DC leaf, storage networking and NVMe storage.
IPv4 and IPv6 support with full L2/L3 features and PTP 1588V2 for Boundary Clock, Transparent Clock, End to End/Peer to Peer Transparent Clock.
HPE Aruba Networking IMC Orchestrator and Analyzer for enhanced network operations with orchestration, automation, and analytical capabilities.
New made in USA TAA-compliant SKUs offer heightened security via manual and automated source code analysis to
address common programming issues, easing concerns about "made in China" products.

High-density, Advanced, Data Center Switches with HPE Aruba Networking IMC Orchestrator and Analyzer

The HPE Networking Comware Switch Series 5945 enables customers to scale their server-edge 1/10/25/40/100GbE top-of-rack (ToR) deployments with high-density 48 x 10GbE (SFP or BASE-T) with 6 x 40GbE ports, 48 x 10GbE (SFP or BASE-T) with 6 x 100GbE ports, 32 x 40GbE ports, and 32 x 100 GbE ports.
Available with a 2-slot modular version delivering two 40GbE or 100GbE ports, 48 x 10/25GbE, 4 x 100GbE, or up to 16 x 100GbE from modules.
A 4-slot modular version is also available with four 40GbE ports.
HPE Aruba Networking IMC Orchestrator and Analyzer offers enhanced network operations with orchestration, automation, and analytical capabilities.

High-performance Data Center Switching

The HPE Networking Comware Switch Series 5945 delivers up to 2.56 Tbps switching capacity for demanding data center applications.
Supports up to 1904 MPPS throughput for data-intensive environments.
Low latency, under 1µs for 40GbE, delivering increased network throughput.
VXLAN support for network virtualization and overlay solutions for improved flexibility. Includes Open vSwitch Database (OVSDB) for dynamic VXLAN tunnel management.

Business Agility and Resilience with Hewlett Packard Enterprise Comware 7

The HPE Networking Comware Switch Series 5945 delivers Hewlett Packard Enterprise Intelligent Resilient Fabric (IRF) with <50 msec convergence time enabling faster application response time.
The In-Service Software Update (ISSU) enables high availability with modular updates accomplished without a reboot or power cycle, in the background.

Simplicity and Lower TCO

HPE Networking Comware Switch Series 5945 simplifies switch management by up to 88% with 9-unit Hewlett Packard Enterprise Intelligent Resilient Fabric (IRF).
No hidden costs with simple one license per switch for all operating system features.
All switch ports are active and ready to use without the need for activation licenses.
