HPE
$323.95S6X56A#ABA
01
The HPE CW 2150 8-port switch is a manageable Layer 3 model with Gigabit Ethernet and 10 Gigabit Ethernet support. It includes two SFP slots and two SFP+ slots for flexible fiber connectivity, with a 16 W power consumption rating.
SKU: S6X56A#ABA
Features
Key Features
- Ethernet Switch supports network continuity by maintaining data transmission during operation
- Allows connection between separate networks to support infrastructure flexibility and structured traffic distribution
- Stack port supports interconnection with other ethernet switch units within a stack
- Features 8 networking ports to establish a local wired network or extend connectivity within an existing layout
- AC power source provides required electrical input for normal device functionality
- Layer 3 switching support enables structured traffic management without altering established network architecture
- Managed capability enables configuration and monitoring functions that support structured network operation
- Gigabit Ethernet supports higher uplink data rates compared to standard Ethernet server connections
- Twisted pair cable support enables cost?efficient network connections for data transmission across distances
Switch
CW 2150
Product Information
Features
Dimensions
Product Name:
CW 2150 8p 10M/100M/1G 2p SFP 1G 2p SFP+ 1G/10G Switch
Product Series:
CW 2150
Product Line:
-
Port Details:
2x Gigabit Ethernet Expansion Slot
8x Gigabit Ethernet Network Port
1x USB Port
1x Out of Band Management Port
2x 10 Gigabit Ethernet Expansion Slot
1x USB Type-C Console Port
1x RJ-45 Console Port
8x Gigabit Ethernet Network Port
1x USB Port
1x Out of Band Management Port
2x 10 Gigabit Ethernet Expansion Slot
1x USB Type-C Console Port
1x RJ-45 Console Port
Rack Units:
-
Fanless:
Yes
Routing:
Yes
Stacking:
Yes
Redundant PSU:
No
PoE Budget (W):
-
Power Consumption (W):
16
Height:
10.6 in
Width:
13.9 in
Depth:
3.4 in
Weight:
3.97 lb
Description
The HPE Networking CW 2150 Switch Series delivers fully managed, stackable Layer 3 switching for small and midsize businesses and branch offices. Designed to balance affordability and performance, the series provides simple management and secure, reliable connectivity to support growing SMB networks.
Maximize your HPE Networking CW 2150 Switch Series | What's New
- Enterprise-class, fully managed, stackable Layer 3 switch series with 8-, 16-, 24-, and 48-port models
- Flexible connectivity options with two 1G SFP and two 1G/10G SFP+ uplinks in the 8-port model
- Advanced Quality of Service (QoS), IPv6, and dynamic L3 protocols (RIP and OSPF) for reliable connectivity
- Supports IEEE 802.3az standard for Energy Efficient Ethernet (EEE)
- Managed by Web GUI, CLI, Smart Management Center (SmartMC) web dashboard, HPE Intelligent Management Center (IMC), SNMP, and REST APIs
Enterprise-class secure and reliable connectivity
- The HPE Networking CW 2150 Switch Series offers flexible connectivity with two 1G SFP plus two 1G/10G SFP+ uplinks on the 8-port model.
- Advanced Quality of Service (QoS), Internet Protocol version 6 (IPv6) and dynamic L3 protocols (RIP and OSPF) for reliable connectivity
- It supports IEEE 802.3az Energy Efficient Ethernet.
Powerful PoE capabilities
- The HPE Networking CW 2150 Switch Series provides Class 4 PoE across the 8-, 16-, 24-, and 48-port models.
- It supports advanced PoE features, including fast PoE that delivers power within seconds of system startup.
