JuniperB1-Q512048YMO-A-A5
Out of stock
Juniper QFX5120-48Y Ethernet Switch - Manageable - 100 Gigabit Ethernet - 100GBase-X - 3 Layer Supported - Modular - 450 W Power Consumption - Optical Fiber - 1U - Rack-mountable - 1 Year Limited Warranty
SKU: B1-Q512048YMO-A-A5
Features
Key Features
- Effectively reduces downtime with improved network performance
- Cascade to other network devices through the uplink port to expand your local area network
- Can work as layer 3 routing for scalable network design
- Rack mounting enables you to organize wires & secure cables for professional installation
- Management capability allows maximum efficiency and with unrestricted control
- 100 Gigabit Ethernet provides high bandwidth performance, ease of use and reliability for your network backbone
- Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
Switch
QFX
Product Information
Features
Dimensions
Product Name:
QFX5120-48Y Ethernet Switch
Product Series:
QFX
Product Line:
QFX
Port Details:
8x 100 Gigabit Ethernet Expansion Slot
48x 25 Gigabit Ethernet Expansion Slot
48x 25 Gigabit Ethernet Expansion Slot
Rack Units:
1U
Fanless:
No
Routing:
Yes
Stacking:
No
Redundant PSU:
Yes
PoE Budget (W):
-
Power Consumption (W):
450
Height:
1.72 in
Width:
17.36 in
Depth:
20.48 in
Weight:
23.7 lb
Description
The QFX5120 delivers low-latency, native 25GbE, rich Layer 2 and Layer 3 features, VXLAN overlay support, and 100GbEoverlay support, and 100GbE uplinks, making it the ideal switch for access and top-of-rack deployments.
Featuring Layer 3 gateway capabilities for bridging between virtualized and bare-metal servers, the QFX5120 is designed for extremely agile data centers that demand support for overlay/ underlay network architectures. The high-density 10GbE, 25GbE, 40GbE, and 100GbE ports also make the QFX5120 ideally suited for deployment as leaf-and-spine and leaf topologies.
