SupermicroSYS-A21GE-NBRT-G1
Out of stock
Power your most intensive workloads with this high-performance 10U single-node server, expertly engineered for High Performance Computing, Conversational AI, AI/Deep Learning Training, Business Intelligence & Analytics, and Industrial Automation. Driven by dual Intel® Xeon® Platinum 8570 processors, delivering a combined 112 cores, and bolstered by 32 high-speed 96GB DDR5-6400 RDIMM memory modules, this system ensures exceptional processing power and responsiveness. Storage is optimized for speed and capacity with 2x 1.9TB M.2 NVMe drives and 8x 3.8TB U.3 NVMe drives. Accelerate your AI initiatives with the cutting-edge 8 NVIDIA HGX B200 GPUs. High-bandwidth connectivity is guaranteed through 8x 400GbE OSFP ports, a 200GbE DPU, and 2x 10GbE RJ45 LAN ports, facilitating seamless data transfer. Ready to deploy immediately, this robust server ships within 24 hours, minimizing downtime and maximizing productivity.
SKU: SYS-A21GE-NBRT-G1
Features
Key Features
- CPU - Dual Intel® Xeon® Platinum 8570 Processor (56-Cores)
- GPU - 8x NVIDIA HGX B200
- Chassis - 10U / 1 Node
- Drive - 2x 1.9TB M.2 NVMe + 8x 3.8TB U.3 NVMe
- RAM - 32x 96GB DDR5-5600 RDIMM Memory
- Network Ports - 8x 400GbE OSFP + 1x 200GbE DPU + 2x 10GbE RJ45 LAN Ports
Use Cases
Scientific Research
Conversational AI
Business Intelligence & Analytics
Drug Discovery
Finance Services and Fraud Detection
AI/Deep Learning Training and Inference
Large Language Model (LLM) and Generative AI
High Performance Computing (HPC)
Autonomous Vehicle Technologies
Motherboard
Super X13DEG-D
System BIOS
GPU
System Memory
On-Board Devices
Input / Output
Management
Security
PC Health Monitoring
Processor
BIOS Type:
AMI 32MB UEFI
Max GPU Count:
8x onboard GPUs
Supported GPU:
NVIDIA SXM: HGX B200 8-GPU (180GB)
CPU-GPU Interconnect:
PCIe 5.0 x16 CPU-to-GPU Interconnect
GPU-GPU Interconnect:
NVIDIA® NVLink® with NVSwitch™
Memory:
Slot Count: 32 DIMM slots
Max Memory (1DPC): Up to 4TB 5600MT/s ECC DDR5 RDIMM
Max Memory (2DPC): Up to 8TB 4400MT/s ECC DDR5 RDIMM
Max Memory (1DPC): Up to 4TB 5600MT/s ECC DDR5 RDIMM
Max Memory (2DPC): Up to 8TB 4400MT/s ECC DDR5 RDIMM
Memory Voltage:
1.1V
Chipset:
System on Chip
Network Connectivity:
2x RJ45 10GbE
USB:
2x USB 3.0 Type-A ports(Front)
Video:
1x VGA port
TPM:
1x TPM header
Software:
SuperCloud Composer®
Supermicro Server Manager (SSM)
Supermicro Update Manager (SUM)
Supermicro SuperDoctor® 5 (SD5)
Super Diagnostics Offline (SDO)
Supermicro Thin-Agent Service (TAS)
SuperServer Automation Assistant (SAA) New!
Supermicro Server Manager (SSM)
Supermicro Update Manager (SUM)
Supermicro SuperDoctor® 5 (SD5)
Super Diagnostics Offline (SDO)
Supermicro Thin-Agent Service (TAS)
SuperServer Automation Assistant (SAA) New!
Power Configurations:
Power-on mode for AC power recovery
ACPI Power Management
ACPI Power Management
Hardware:
Trusted Platform Module (TPM) 2.0
CPU:
Monitors for CPU Cores, Chipset Voltages, Memory
8+4 Phase-switching voltage regulator
8+4 Phase-switching voltage regulator
Fan:
Fans with tachometer monitoring
Status monitor for speed control
Pulse Width Modulated (PWM) fan connectors
Status monitor for speed control
Pulse Width Modulated (PWM) fan connectors
Temperature:
Monitoring for CPU and chassis environment
Thermal Control for fan connectors
Thermal Control for fan connectors
CPU:
Dual Socket E (LGA-4677)
5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors
5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors
Cores:
Up to 64C/128T; Up to 320MB Cache per CPU
Note:
Supports up to 350W TDP CPUs (Air Cooled)
Chassis
CSE-GP1001TS-R000NPF
Front Panel
Expansion Slots
Drive Bays / Storage
System Cooling
Operating Environment
Power Supply
Dimensions
Environmental / Recycling
Buttons:
Power On/Offa0
UID/ Reset button
UID/ Reset button
LED:
HDD activity
Network activity LEDs
System information (overheat/UID)a0
UID
Network activity LEDs
System information (overheat/UID)a0
UID
PCI-Express (PCIe) Configuration:
Default
8x PCIe 5.0 x16 LP slots
2x PCIe 5.0 x16 FHHL slots
8x PCIe 5.0 x16 LP slots
2x PCIe 5.0 x16 FHHL slots
Drive Bays Configuration:
Default: Total 10 bays
10x front hot-swap 2.5" PCIe 5.0 x4 NVMe* drive bays
(*NVMe support may require additional storage controller and/or cables)
10x front hot-swap 2.5" PCIe 5.0 x4 NVMe* drive bays
(*NVMe support may require additional storage controller and/or cables)
M.2:
2x M.2 PCIe 3.0 x4 NVMe slots (M-key 2280/22110; VROC required for RAID)
Fans:
15x heavy duty hot-swappable 80mm Fan(s)
4x heavy duty internal 60mm Fan(s)
4x heavy duty internal 60mm Fan(s)
Environmental Spec.:
Operating Temperature: 10°C to 35°C (50°F to 95°F)
Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
Configuration:
6x 5250W Redundant (3 + 3) Titanium Level (96%) Hot-plug power supplies
Dimension (W x H x L):
106.5 x 82.1 x 245.3 mm
Input:
5250W: 200-240Vac / 50-60Hz
+12V:
Max: 125A / Min: 0A (200Vac-240Vac)
12V SB:
Max: 4A / Min: 0A
Output Type:
Backplanes (gold finger)
Certification:
Titanium Level
Height:
17.2 in
Width:
17.6 in
Depth:
33.2 in
Package Height:
25.2 in
Package Width:
49.4 in
Package Depth:
27.3 in
Gross Weight:
341.06 lb
Net Weight:
292.99 lb
Available Color:
Silver
Form Factor:
10U Rackmount
Model:
CSE-GP1001TS-R000NPF
Recycle:
Contact us at lifecycle@rackables.com for recycling options.
Part NumberQtyDescription
8x Power Supply optional parts
PWS-3K06G-2R 2AC-DC 3000W, Titanium efficiency, DC output: 54Vdc/45A
8x SATA optional sets
CBL-GNZ2-1221MTS41GenZ 2C+2 mount holes to SlimSAS x8,21cm,31AWG,RoHSMCP-220-00147-0B 5Black gen-3 hot-swap 2.5" Tool-less HDD tray (clip design)
Side expention sets
AOM-DP801-PCIE-P1NIC Riser board(After Mid-Plane) for Delta-Next GPU System,RoHSAOM-DP801-SW-P1NIC adaptor board with PLX switch for Delta-Next GPU system,RoHSCBL-PWEX-1142B-40 1MicroHi(2x4 to 2x4), PH3.0, 40cm, 8.5A/p, 18AWG, RoHSCBL-MCIO-1255M5 4MCIO x8 (STR to STR),55CM,30AWG,RoHS
